The Bolide BN-NVR/16NX-S/NDAA is a 16-channel network video recorder designed for IP surveillance systems requiring integrated Power over Ethernet, 4K-capable recording, and AI-enabled video analytics. It includes 16 PoE ports, supports up to 8MP recording resolution, and provides 112Mbps of recording throughput.
The NVR combines Bolide's iPac AI features with perimeter and video analytics, including face recognition, human and vehicle detection, perimeter intrusion detection, line crossing, stationary object detection, pedestrian detection, people counting, and foot-traffic heat maps. It also supports two internal SATA hard drives with up to 12TB per bay for a total supported capacity of 24TB.
Key Features
- 16-channel IP network video recorder
- 16 integrated PoE ports
- Supports up to 8MP / 4K recording
- 112Mbps recording throughput
- Up to 45 FPS at 4K
- Up to 90 FPS at 4MP
- Up to 180 FPS at 2MP
- iPac AI-enabled video analytics
- Face recognition
- Human and vehicle detection
- Perimeter intrusion and line-crossing detection
- Stationary object detection
- Pedestrian detection
- People and cross counting
- Foot-traffic heat map
- Two SATA hard-drive bays
- Up to 12TB per hard-drive bay
- Up to 24TB total internal storage capacity
- HDMI and VGA video outputs
- ONVIF Profile S Version 2.6
- Gigabit Ethernet connectivity
- 8 alarm inputs and 1 alarm output
- Bolide Quick Connect mobile access for iOS and Android
- NDAA compliant
16-Channel Recording
The BN-NVR/16NX-S/NDAA provides 16 IP camera channels for centralized recording and monitoring. It supports recording resolutions from 1MP through 8MP, allowing the recorder to accommodate cameras with different resolution requirements within the same surveillance system.
4K Recording Performance
The NVR supports 8MP recording and specifies a recording frame rate of up to 45 FPS at 4K. Bolide also specifies up to 90 FPS at 4MP and up to 180 FPS at 2MP. Actual recording performance depends on the connected cameras, stream configuration, compression settings, and available network bandwidth.
Integrated 16-Port PoE
Sixteen built-in PoE ports allow compatible IP cameras to receive network connectivity and power directly from the NVR. Each PoE port supports up to 30W through IEEE 802.3at, simplifying installation by reducing the need for a separate PoE switch for supported camera configurations.
iPac AI Video Analytics
The BN-NVR/16NX-S/NDAA incorporates Bolide's iPac AI functionality for supported intelligent video-analysis features. The manufacturer lists face recognition and human/vehicle detection in addition to several perimeter and scene analytics.
- Face recognition
- Human detection
- Vehicle detection
- Pedestrian detection
- Perimeter intrusion detection
- Line crossing detection
- Stationary object detection
- Cross counting
- People counting
- Foot-traffic heat map
AI functions depend on compatible camera streams, firmware, and system configuration. Analytics should be configured according to the surveillance environment and intended application.
High-Capacity Internal Storage
The recorder provides two internal SATA hard-drive bays. Bolide specifies support for up to 12TB per bay, allowing up to 24TB of total internal storage capacity when compatible drives of the maximum supported capacity are installed.
Hard drives are not specified as included in the manufacturer's listed configuration. Actual recording retention depends on installed storage, camera resolution, frame rate, compression, scene activity, and recording mode.
Display Outputs
The BN-NVR/16NX-S/NDAA includes one HDMI output and one VGA output. Supported display resolutions range from 1024 × 768 through 3840 × 2160, including 4K output at 3840 × 2160.
Network and Camera Compatibility
A 1000M RJ-45 network interface provides Gigabit Ethernet connectivity. The NVR supports ONVIF Profile S Version 2.6 for integration with compatible IP cameras and surveillance equipment.
Alarm and Audio Interfaces
- 8-channel alarm inputs
- 1-channel alarm output
- 1-channel audio input
- 1-channel audio output
- Line input
Remote Mobile Access
Bolide Quick Connect provides remote mobile access through compatible iOS and Android devices. This allows supported surveillance systems to be accessed remotely using compatible Bolide mobile software.
Technical Specifications
- Model: BN-NVR/16NX-S/NDAA
- Product Type: 16-Channel Network Video Recorder
- Channel Capacity: 16 channels
- PoE Ports: 16
- PoE Standard: IEEE 802.3at
- Maximum PoE Output: 30W per port
- Recording Throughput: 112Mbps
- Recording Resolution: 8MP, 5MP, 3MP, 2MP (1080P), 1.3MP (960P), 1MP (720P)
- Frame Rate: 4K: 45 FPS; 4MP: 90 FPS; 2MP: 180 FPS
- Display Split: 1 / 4 / 9 / Custom
- Video Outputs: 1 HDMI, 1 VGA
- Maximum Display Resolution: 3840 × 2160
- Network: 1000M RJ-45 Ethernet
- ONVIF: Profile S Version 2.6
- Internal Storage: 2 × SATA HDD bays
- Maximum HDD Capacity: 12TB per bay / 24TB total
- Alarm Input/Output: 8-channel input / 1-channel output
- Audio: 1-channel input / 1-channel output
- USB: 2 × USB 2.0
- Mobile Access: Bolide Quick Connect for iOS and Android
- Power Supply: DC 48V
- Dimensions: 14.88" W × 12.47" D × 1.88" H
- Compliance: NDAA compliant
Installation Considerations
The integrated 16-port PoE design makes the BN-NVR/16NX-S/NDAA suitable for installations where compatible IP cameras can be connected directly to the recorder. Camera power requirements should be checked before installation to ensure they remain within the available PoE specifications.
For larger systems or cameras requiring more power than the specified per-port limit, additional network or PoE equipment may be required.
Product Summary
The Bolide BN-NVR/16NX-S/NDAA provides a centralized recording platform for up to 16 IP cameras with integrated 16-port PoE, 4K recording support, iPac AI analytics, ONVIF compatibility, alarm and audio interfaces, and up to 24TB of internal storage. Its compact design makes it suitable for commercial, residential, institutional, and other IP surveillance installations requiring an integrated NVR and PoE solution.
