The Bolide BN-NVR/8NX-S/NDAA is an 8-channel network video recorder designed for IP surveillance systems requiring integrated Power over Ethernet, high-resolution recording, video analytics, and iPac AI capabilities. It provides eight built-in PoE ports for compatible IP cameras and supports recording resolutions up to 8MP (4K).
Key Features
- 8-channel network video recorder
- 8 built-in PoE ports for compatible IP cameras
- Supports recording resolutions up to 8MP (4K)
- 128Mbps maximum recording throughput
- iPac AI with face recognition and human/vehicle detection
- Video analytics including perimeter intrusion, line crossing, stationary object, and pedestrian detection
- Cross and people counting with foot traffic heat map
- Supports up to two SATA hard drives, up to 12TB per bay
- HDMI and VGA video outputs
- ONVIF Profile S Version 2.6
- Gigabit Ethernet connectivity
- Bolide Quick Connect mobile access for iOS and Android
- NDAA compliant
4K Recording and High-Resolution Support
The BN-NVR/8NX-S/NDAA supports IP cameras with recording resolutions of up to 8MP (4K), along with 5MP, 3MP, 2MP (1080P), 1.3MP (960P), and 1.0MP (720P) options. Maximum listed frame rates are 45 FPS at 4K, 90 FPS at 4MP, and 180 FPS at 2MP, depending on the recording configuration and connected cameras.
Integrated 8-Port PoE
Eight built-in PoE ports provide both network connectivity and power to compatible PoE IP cameras through the network connection. Each PoE port supports up to 30W using IEEE 802.3at, helping simplify installation by reducing the need for separate power connections at each camera location.
iPac AI and Video Analytics
The recorder supports iPac AI features including face recognition and human/vehicle detection. Additional video analytics include:
- Perimeter intrusion detection
- Line crossing detection
- Stationary object detection
- Pedestrian detection
- Cross counting
- People counting
- Foot traffic heat map
AI and analytics functionality can depend on compatible camera models, firmware, configuration, and available camera-side features.
Storage Capacity
The BN-NVR/8NX-S/NDAA provides two SATA hard drive bays, supporting up to 12TB per bay for a total supported capacity of up to 24TB. Hard drives are not specified as included with the recorder and may need to be purchased separately.
Video Output and Display
The recorder features one HDMI output and one VGA output. Supported display resolutions include up to 3840 × 2160, allowing the recorder to be connected to compatible 4K displays.
Network and Mobile Access
A 1000M RJ-45 network connection provides Gigabit Ethernet connectivity. The BN-NVR/8NX-S/NDAA also supports ONVIF Profile S Version 2.6 for compatibility with supported IP surveillance equipment and can be accessed through the Bolide Quick Connect mobile application for iOS and Android.
Audio and Alarm Connections
- 1-channel audio input
- 1-channel audio output
- 8-channel alarm inputs
- 1-channel alarm output
Technical Specifications
- Model: BN-NVR/8NX-S/NDAA
- Channels: 8
- PoE Ports: 8
- Maximum Recording Bandwidth: 128Mbps
- Recording Resolutions: 8MP, 5MP, 3MP, 2MP (1080P), 1.3MP (960P), 1.0MP (720P)
- Maximum Frame Rate: 4K: 45 FPS; 4MP: 90 FPS; 2MP: 180 FPS
- Video Outputs: 1 HDMI, 1 VGA
- Audio: 1-channel input / 1-channel output
- Alarm: 8-channel input / 1-channel output
- Network: RJ-45 1000M
- Storage: 2 SATA bays, up to 12TB per bay
- Maximum Supported Storage: 24TB total
- USB: 2 × USB 2.0
- ONVIF: Profile S Version 2.6
- PoE Standard: IEEE 802.3at
- PoE Power: Up to 30W per port
- Power Supply: DC48V / 48V PoE switch
- Mobile Access: Bolide Quick Connect for iOS and Android
- Dimensions: 14.88" W × 12.47" D × 1.88" H
- Compliance: NDAA compliant
Important Notes
- Hard drives are not specified as included and may need to be purchased separately.
- Camera compatibility and actual recording performance depend on the connected cameras, network configuration, and system settings.
- AI and analytics features may require compatible cameras and appropriate configuration.
